MLR56
MLR56
120V and 277V
6" LED Recessed Downlight For direct ceiling
120V and 277V
6" LED Recessed Downlight For direct ceiling
Description
6" aperture promotional LED housing with 120V, 12.5W AC LED Module, integral triac dimmable by most of leading and trailing edge dimmer switches in the market. The MLF56 is designed for use in new construction or remodel applications with insulated ceilings. Thermally protected. Suitable for wet locations.Features & Functions
- One piece light engine with durable heat sink and LED
- Durable die-casting aluminum heat sink with integrated trim in one-piece
- (2)mounting clips on trim module for use of remodeling version
- J-box: - Installed on the top of fixture with (1)3/4" knockout. Listed for through branch circuit wiring (max. 8 No. 12 AWG 90° Concuctions. Ground wire provided
- 120V AC LED module with integrated IC chip imbed on board
- Triac dimmable standard
Listing
- CSA-us Certificated
- State of California Title 24
- Energy Star Approved & Listed
- Wet location
Warranty
- 5 years of lamp life
Mounting Frame (Optional)
- Plaster frame (7-1/8" x 7-1/8") for new construction
- HB-24 bar hangers are option for use with new construction
- MLR56 Specification Sheet (486.09 KB)
